PREPARATION
The connection parameters must be the same on the DNC as on the
HyperTerminal.
DNC 600S Parameters
RS232/STOPS/DIVERSE
104 DWELL TIME IN MINUTES _
---- COMPUTER LINK ----
106 BAUD RATE 57600 STOP 1.0
PARITY ODD (1) EVEN (0) BITS 8
PROTOCOLE_ BCC
Protocole: The number of DNC pages printed on a page is
indicated in this field.
According to the indicated number, DNC sends a
page-feed to the printer.
Example:
1 = 1 DNC page per printer page.
2 = 2 DNC pages per printer page.
If nothing is programmed, the pages are sent one
after the other.
defines the left margin in characters
(spaces).
left margin= 2 + (BCC x 2)
Field: 0 (2 characters) to 9 (20 characters)
Example: BCC = 4, i.e. 2 + (4 x 2) = 10
LAfter having modified the parameters:
• Go to the TRANSFER page.
• Select 1 then hit the
BCC: this field
key to confirm the transmission with the
new parameters, or turn the DNC off and on again.
PAGE 84 USER GUIDE DNC 600S
