10
2. Advanced Power Management
Intelligent PDU Web Interface
2. Advanced Power Management
2.1 Remote Monitoring
Users can see real-time readings of PDU vitals such as device load, power
consumption, and outlet status for an overview of current PDU status. See Summary
Tab, PDU Tab > Status, and PDU Tab > Status > Outlet.
Summary Tab
Item Definition
HOST/GUEST#
Select the role of PDU (HOST or GUEST#) if PDUs are daisy
chained. Up to 3 GUEST PDUs can connect to 1 HOST PDU.
Current
Condition
Operating condition of the PDU and ENVIROSENSOR.
PDU Status
Dev Load To ta l l oad current of all connected devices, measured in Amps.
Outlet
The on/off status of each outlet. The green light icon indicates
that the outlet is on and providing power. This light will go off
when the outlet turns off.
Outlet Tooltip Function: move the cursor to an individual outlet,
Outlet name and its ON/OFF status will be shown.
