Intelligent PDU Web Interface
APPENDIX
Appendix B: Firmware Upgrade
By upgrading the Firmware, you can obtain new features and updates/improvements to
existing functionality. To ensure the firmware is kept up to date, please regularly visit our
website to see if there is any updated firmware version available. There are three
methods for upgrading the PDU firmware. Please follow the instructions below for the
method that is appropriate for your application. There are two files to update in order to
upgrade the firmware version:
* cpsmpdumafw_XXX.bin
* cpsmpdumadata_XXX.bin
Note that the XXX is not part of the file name but is where the version number in the
filename is given.
Prior to performing a firmware update, please:
• Download the latest firmware from www.cyberpower.com
• Extract the downloaded firmware file to your local “C:\” drive
Note:
1. The FTP service needs to be enabled before attempting to execute a firmware
upgrade. Please refer to 5.7 FTP Service to make sure that FTP is enabled.
2. Please do not turn the PDU off when processing the Firmware upgrade. PDU outlets
will remain powered on while the firmware update takes place. Only the PDU LCD
screen will reboot.
3. The PDU LCD screen will reboot during the firmware update process. This DOES NOT
cause the PDU outlets to reboot.
Option 1: Single Device Upgrade via FTP
Use the following steps to upgrade the firmware.
1. Open a command prompt window and navigate to “C:\”.
2. Login to the PDU with FTP command, type
- C:\>ftp
- ftp> open 192.168.22.126 21 (for example: 192.168.22.126 is the current IP of
the PDU and 21 is the default ftp port for the PDU)
- Connected to 192.168.22.126.
- 220 CyberPower FTP Server Ready.
- User (192.168.22.126:(none)):cyber
- 331 User name okay, need password.
- Password:
- 230 User logged in, proceed.
- ftp>
