CyberPower PDU31 Series User Manual

15
2. Advanced Power Management
Intelligent PDU Web Interface
Log Tab > Graphing
Item Definition
HOST/GUEST#
Select the role of PDU (HOST or GUEST#) if PDUs are daisy
chained. Up to 3 GUEST PDUs can connect to 1 HOST PDU.
Graph Period
The time period is used to create a retroactive graph of the
status records. A large time period will require more time to
render the graph.
Graph Data
The data used to create a graph of the status records. Up to
five data points can be selected. A large number of data
selected will require more time to render the graph.
Graph Node
Select the Display All Nodes in Detail option to display the
selected data points along the grap
h. When the cursor is
moved to an individual data point, information about that
point will be shown.
If this option is not selected, the graph will show only the
line (without the points), so less time is needed to render.
Draw A graph of the status records will be created.
Reset Reset the Graph Period to default (1 day).
Launch Graph in New
Window
A detailed view of the graph opens in a new browser
window.
