Parts List
Page C-1
Cybex 750T Treadmill Owner’s Manual
ITEM QTY. PART NO. DESCRIPTION
1 2 AF-19988 NUT, ROLLER, REAR
2 2 AF-20052 BRACKET, MOTOR,MOUNTING
3 2 AF-20206 CLAMP, LOWER, TOP STEP
4 1 AL-19740 ROLLER ASSY, FRONT
5 1 AL-19741 ROLLER ASSY, REAR
6 2 AX-20035 ASSY, DECK PIVOT BRACKET
7 1 AX-20094 ASSY, ELEVATION
8 1 AX-20383 ASSY, MOTOR COVER
9 1 AX-20452 ASSY, END CAP, LEFT
10 1 AX-20453 ASSY, END CAP, RIGHT
11 1 BD-19889 BELT, RUNNING, 21.88 X 61.75”
12 1 BD-20049 BELT, DRIVE
15 1 DE-14486 DECAL SERIAL NUMBER
16 1 DE-18413 DECAL, ETL AND CSA
17 2 DE-19360 DECAL, CYBEX, BLACK
18 2 DE-20392 DECAL, 750T, BLACK
19 2 DE-20393 DECAL, 750T, SILVER
20 1 DE-20427 DECAL, DISCONNECT POWER
21 1 DK-20024 DECK, RUNNING, 29.00 X 53.5”
23 4 EH-10291 TY WRAP BASE
24 2 FM-20096 PIN, ELEVATION PIVOT
25 1 FM-20099 MOUNTING SHAFT, ELEVATION
MOTOR
26 4 FS-16511 PLATE, REAR RUBBER FOOT
MOUNT
27 2 FS-20031 PLATE, RETAINER, UPPER, TOP
STEP
28 1 FS-20109 SHIELD, SPLASH
29 1 FT-16825 SLEEVE, ELEVATION MOUNTING,
TOP
30 1 FT-16826 SLEEVE, ELEVATION MOUNTING,
BOTTOM
31 2 HB-16367 BUSHING .50 ID X .62 OD X .31”
32 2 HB-20097 BEARING, FLANGE, BRONZE
33 2 HB-20098 BEARING, THRUST, BRONZE
34 4 HN-11136 KEPS 5/16” HEX STL ZINC
35 2 HN-17935 NUT LOCK, 3/8 - 24
36 2 HN-20041 NUT, 1/4 - 20 PROPELLER
37 2 HN-20693 NUT, TEE, 5/16 - 18, 1-2” BARREL
38 4 HS-00700 SCREW, 8-32 X 0.50”, PNHD PHIL
39 17 HS-11977 SCREW SEMS, 8-32 X .38, PNHD
PHIL
40 12 HS-12295 BOLT, 1/4 - 20 X 1.75”, HXHD, G5
41 2 HS-15480 BOLT TAP, 1/2 - 13 X 6, HXHD, G5
42 9 HS-15706 SCREW, 8-16 X .50”, PNHD, STL,
BLK ZN
43 8 HS-16509 SCREW SLFTP, 10 X .5”, PNHD,
PLT, TYP
44 8 HS-16929 BOLT WHIZ LOCK, 3/8 - 16 X .625”,
HXHD
45 4 HS-16939 SCREW SEMS, 10-32 X .75, PNHD,
BLK
46 1 HS-17936 BOLT, 3/8 - 24 X 2.0”, HXHD CAP
47 1 HS-17937 BOLT, 3/8 - 24 X 2.75”, HXHD CAP
48 2 HS-18358 BOLT, 5/16 - 18 X .1.25”, SCHD CAP
49 8 HS-19108 SCREW 5/16 - 18 X 3/4”, HXHD
51 12 HW-00180 WASHER, SPLIT LOCK 1/4”, SST
52 2 HW-00590 BUSHING, NYLON, 1/2”
53 2 HW-10028 WASHER, 1/2”
54 14 HW-18123 WASHER, .344 ID X .75 OD X .125”
55 2 HW-20044 WASHER, BELLEVILLE, 15 X 8.2 X
1.0 mm
ITEM QTY. PART NO. DESCRIPTION
56 2 HW-20089 WASHER, WAVE, .650 ID X .855”
57 4 HW-53017 WASHER FLAT, 5/16”, SS
58 7 HX-13771 RING, RETAINING, 5/8” 0.579 ID
59 2 HX-19102 FOOT, RUBBER, REAR
60 2 HX-19991 BUMPER, SPRING DECK, 2.10 X
2.34 X 1”
62 1 PL-20262 COVER, LEFT SIDE FRONT
63 1 PL-20263 COVER, RIGHT SIDE FRONT
64 1 PL-20264 COVER, FRONT
65 1 PL-20265 COVER, REAR, FRAME OUTER,
LEFT
66 1 PL-20266 COVER, REAR, FRAME INNER,
LEFT
67 1 PL-20269 COVER, REAR, FRAME OUTER,
RIGHT
68 1 PL-20270 COVER, REAR, FRAME INNER,
RIGHT
69 2 HS-41107 BOLT, 5/16 - 18 X 1.5”, BTHD, SST
70 2 HW-00165 WASHER, SPLIT LOCK 5/16”
74 2 EH-20254 CLIP,WIRE RETAINER,.24-.47”,
DIA,.105THK
75 1 HX-20248 GROMMET,RUBBER,1.12”DIA
76 2 EH-20244 CLIP, WIRE RETAINER, .24-.47”DIA
77 1 DE-19198 DECAL,CYBEX
81 1 AF-20842 BRACKET, MOTOR COVER
82 1 HS-11976 SCREW, SEMS, 10-32 X .38”
83 1 HX-20843 BUMPER, MOTOR COVER
84 1 HN-60064 NUT, JAM, 3/8 - 16”, BLACK ZN
85 1 HS-60022 BOLT, 3/8 X 2.25”, HXHD, CAP,
BLK
86 1 CW-22240 WHEEL,80MM DIA X 32MM W
87 2 HX-22247 BUSHING,SPANNER,.500 OD X
1.5”L
89 2 HS-22137 BOLT, 1/4-14 x 1.25”,HXHD
WSHR,TYP
90 2 PL-22129 BRACKET,POWER CORD
STORAGE,PLASTIC
91 5 EH-00986 TY WRAP 9”
92 1 DE-22327 LABEL,BLACK,INTELLIGENT
SUSPENSION 3
92 1 DE-22328 LABEL,SILVER,INTELLIGENT
SUSPENSION 3
101 1 MR-22239 ASSY, MOTOR, TREADMILL, AC
DRIVE
102 1 AX-20235 SUB ASSY, 110 VAC
CONTROLLER
102 1 AX-20236 SUB ASSY, 220 VAC
CONTROLLER
102 1 AX-20237 SUB ASSY, 230 VAC, 50HZ
CONTROLLER
103 1 MR-19992 MOTOR, ELEVATION, 115 VAC,
60 HZ
103 1 MR-19993 MOTOR, ELEVATION, 230 VAC,
50-60 HZ
111 1 KAD-22221 PCA, CNTRL, GOLD, 115 VAC
111 1 KAD-22431 PCA, CNTRL, TIN, 230 VAC
111 1 KAD-22223 PCA, CNTRL, GOLD, 230 VAC,
50 HZ
112 1 AD-21879 PCA, HUB BOARD
113 1 AF-20123 PLATE, SWITCHES
114 1 AF-20234 BRACKET,CONTROLLER, PCB
115 1 AW-19404 CABLE, CAT5, RJ45 FLAT PATCH
12”
