Assembly and Set Up
Page 2-5
Cybex Arc Trainer 750A/750AT Owner’s Manual
750AT Contents
Item Qty Part Number Description
1 1 Varies Base with covers attached
2a 1 Varies Console assembly (in box)
3 2 12090-322 Foot pad
4 1 740A-370 Tray, Main
5 1 740A-371 Tray, Insert
6
1 NA Hardware pack
7 1 5750-4 Owner’s Manual
8 1 750A-393 Assembly poster
9 1 750A-391 Commercial Arc warranty sheet
10 1 750A-392
Consumer Arc warranty sheet
NOTE: For 750A assembly, skip to step 7.
5. Unpack and verify 750AT contents of carton.
See 750AT content listing and Figure 2a for 750AT carton contents. A.
Check off each item as found. See B. Customer Service – Chapter 5 for contact information if any
parts are missing.
Figure 2a (750AT)
#7
#8
#9
#10
#5
#2a
#3
#4
#1
#6
To Next Page
