Cybex 750A/750AT Arc Trainer Owner’s Manual
Exploded Views
Page D–12
ITEM NO. QTY. PART NUMBER DESCRIPTION
B1 1 600A-343 BELT, PRIMARY DRIVE
NS 1 630A-314 CLAMP, BATTERY
B3 1 630A-328 BELT, SECONDARY DRIVE, 7 RIB
B4 1 750A-110 DOUBLE PULLEY ASSY
B5 1 750A-111 SINGLE PULLEY ASSY
B6 1 750A-212 WELDMENT, FRAME, FRONT
B7 1 AX-19550 ASSEMBLY, ECB/GEN
B8 2 HC661240 SCREW, HEX HEAD CAP .312-18 x 3.75
B9 4 HC701254 HX HD CAP SCREW .375-16 X 5.50
B10 2 HF579000 PANEL FASTNER, 10-24 U TYPE
B11 4 HN704901 LOCKNUT, .375-16 NYLON
B12 2 HS327600 WASHER, SAE .312
B13 2 HS328300 LOCKWASHER SPLIT .312
B14 8 HS347700 WASHER, USS .375
B15 2 HX-17050 BUSHING, 1.275 ID x 1.87 OD, NYLON
A86 1 DE-17155-X* DECAL, WARNING
B16 1 750A-364 SPACER, GEN WINDING
NS 1 AD-20827 PCA, CONTROL BOARD, EDDY CURRENT
NS 1 AW-18447 CABLE, SPA BATTERY
NS 1 DE-19586 LABEL, WARNING ICON
NS 1 EC-18267 BATTERY, 12 V 7AHR
B21 4 HC702815 SHCS .375-16 X .750
B22 4 HS347600 WASHER, SAE .375
A77 5 HT572512 TAP SC NO. 10-24 X .50 PN HD PHIL
Drive Frame Assembly – Part Number 750A-101
NS = Not Shown
