3. Remove the display overlay.
A. While wearing an ESD strap, disconnect the switch membranes (two upper and one lower)
from the display board. See Figure 19.
B. Use a razor blade to peel up a corner of the display overlay and pull off the overlay.
4. Attach the display overlay.
A. Remove the paper backing from the new display overlay.
B. Slide the ribbon cable through the (upper two or lower one) slot.
C. Carefully place the display overlay in position within the indentation on the console front
and firmly rub the display overlay so that it adheres to the console.
D. Route the ribbon cables under the frame tubes and connect them to the display board.
5. Secure the console covers.
A. Using a Phillips head screwdriver, tighten the six screws that hold the console front to the
frame.
B. While being sure not to pinch any cables, secure the console back to the console with the
five Phillips head screws.
6. Test the new display overlay.
A. Turn the main power switch to the on (I) position.
B. Plug the treadmill into the power outlet.
C. Try each key to be sure that it functions properly.
Parts List
ITEM PART NO. DESCRIPTION
NO.
1 AF-16240 Frame, Weldment
2 HS-16929 Screw, 3-8-16 x 5-8Lg H x HD whiz-lock GR5
3 HS-16950 Screw, 5-16-18 x 7-8Lg H x Soc BTNHD w/patch, B-Zn
4 HS-16939 Screw, SEM 10-32 x .75 Pnhd Ext blk Zn
5 PL-16256 Cover, Motor
6 PL-16465 Cover, Upright Outer, Right
7 PL-16464 Cover, Upright Outer, Left
8 HW-13799 Washer, Flat
9 AX-16721 Deck Stiffener Assy
10 HX-16706 Tape Strip, 1.88 x 41.0 x .010thk
11 HX-16707 Tape Strip, 1.32 x 4.30 x .010thk
12 HS-15682 Screw, 5/16-18 x .50 FLHD Phil undercut ZN
13 AX-17726 Side Extrusion Assy, Cybex Pro+, Right
14 AX-17727 Side Extrusion Assy, Cybex Pro+, Left
15 AF-17677 Upright Weldment (Choose a Standard or Custom Color)
16 AX-16722 Top Platform Assy, (Choose a Standard or Custom Color)
17 DE-16705 Decal, Safety-walk
18 HS-16875 Screw, SEM ext 1-4-20 x 1-2 PNHD Phil
19 EH-10291 Anchor, Cable Tie
20 EH-00986 Cable Tie, (without anchor)
21 PL-16737 Plug, Power Cord Grommet
21 AW-17273 Power Cord 220V 60Hz (NOT SHOWN)
21 AW-17272 Power Cord 230V 50Hz (NOT SHOWN)
21 AW-17274 Power Cord 115V 60Hz (NOT SHOWN)
22 PL-16738 Plug, Power Cord Grommet
Cybex Pro+ Treadmill Owner’s & Service Manual
Service
Page 7-39
