Cybex Pro+ Treadmill Owner’s & Service Manual
Service
Page 7-22
Elevation Motor
Tools Required
• Phillips head screwdriver
• Wooden block 4” (10 cm) tall (2)
• 9/16” Open end wrench
• 9/16” Socket wrench
! WARNING: Disconnect the power cord before beginning this procedure. Keep wet
items away from inside parts of the treadmill. Electrical shock could occur
even if the treadmill is unplugged.
1. Disconnect the external power source.
A. Turn the main power switch on the left side to the off (O) position.
B. Unplug the treadmill from the power outlet.
2. Remove the motor cover.
A. Using a Phillips head screwdriver, loosen three screws on each motor cover side (left
and right). See Figure 2.
B. Lift the motor cover center up and off the treadmill. The screws will stay in place. See
Figure 2.
3. Place wooden blocks under the frame.
! CAUTION: A minimum of two people will be required to properly lift the treadmill.
Always use proper lifting methods when moving heavy items.
A. While two people are lifting the front of the treadmill, have a third person place a
wooden block under the each side of the frame to support the front end of the
treadmill. NOTE: This will get the weight of the treadmill off the elevation wheels and
provide support.
4. Disconnect the elevation motor cable.
! WARNING: Do not touch components on the lower board. A charge can remain after
unplugging the power cord and turning off the treadmill.
A. Pull up on the lower board shield. It will snap out.
B. Disconnect the elevation motor cable from the lower board and remove it from the wire tie.
5. Remove the elevation motor.
A. Using a 9/16” open end wrench and a 9/16” socket wrench, remove the two bolts on
the elevation motor (one at the top and one at the bottom). NOTE: Hold the motor
while you remove the second bolt so that it doesn’t fall.
B. Carefully lift and remove the elevation motor from the treadmill.
To Next Page
