ITEM PART NO. DESCRIPTION
NO.
22 PL-16738 Plug, Power Cord Grommet
23 DE-16992 Decal, ETL UL-1647 Only
24 Removed
25 PC-16496 End Cap, Left, (Choose a Standard or Custom Color)
26 PC-16497 End Cap, Right, (Choose a Standard or Custom Color)
27 HX-15678 Bushing Deck 5/16-18 40 lb max shear 185 max comp
28 EH-16809 Grommet, 1.12 x .091-.125 nylon
29 HX-14416 Clip, Cable Retainer
30 DE-16928 Label, Disconnect Power, Multi-languages
31 HW-00590 Bushing Nylon 1-2” Nf810-5-0
32 HX-13771 Ring, Retain 5-8” .579 Fr.Id
33 HX-16510 Foot, Rubber, Rear
34 FS-16511 Plate, Rear Rubber Foot Mount
35 HS-16509 Screw, #10 x .5LG,T-S PLT, PNHD,TYB-B
36 HS-15480 Bolt, Tap 1/2-13unc x 6 H x HD GR5
37 HB-16367 Bushing, .50ID x .62OD x .31LG, flanged
38 HW-10028 Washer, B 1-2 Narrow Zinc
39 HX-11049 Spring 1" O.D.360 Max Ld.
40 AX-16723 Rear Roller Hardware Assembly
40 AF-17591 Nut Holder Bracket
41 AF-16382 Elevation, Weldment
42 HS-60022 Bolt, Hhcs 0.375 x 2.25 blk zn G5
43 CW-16712 Wheel, Rubber, 3" Dia
44 HN-60064 Nut, Jam 3-8”-16 blk zn
45 DE-17144 Decal, International only, (specify language)
46 HS-60021 Bolt, Hhcs 0.375 x 2 blk zn G5
47 HS-60023 Bolt, Hhcs 0.375 x 2.5 blk zn G5
48 MR-16412 Motor, Elevation 115 VAC
48 MR-16541 Motor, Elevation 230 VAC
49 SK-17079 Tube Nut, Motor, Elevation Kit
50 FT-16825 Sleeve, Elevation Mounting, Top
51 FT-16826 Sleeve, Elevation Mounting, Bottom
52 EC-15783 Filter, Line 20 Amp Spade
52 EC-16948 Filter, Power Line 20 Amp 20EQ1
53 HS-15732 Screw, SEM 8-32 unc x .62 PNHD phil pl
54 HW-10856 Washer, (for ground)
55 HN-11925 Nut, Keps 10-32 Hex Stl Zinc
56 PL-17052-4 Cover, Lower Controller English
57 HX-16943 Clip, Christmas Tree, Single Head
58 SK-17253 Lower Control Assy, 115V
58 SK-17252 Lower Control Assy, 230V
58 SK-17251 Lower Control Assy, 230V 50Hz, International use only
59 DE-16608-4 Brush Replacement Gauge, English
60 DE-16610-4 Label, Error Codes, English
61 DE-16609-4 Label, Service Schedule English
62 DE-19198 Decal, Logo
63 DE-17691-4 Label, User Precautions, 15 x 1.3”
64 DE-17693-4 Label, Start Instructions, Profiles, English
65 DE-17692-4 Label, HR Zone, Heart Icons, English
66 EH-16977 Fan, Drive Motor, Leeson
67 AW-17704 Motor Ground Wire
68 HW-40004 Washer, Wavy
69 AX-17762 Motor Base Plate Assy
70 HS-16849 Screw, 5-16-18 x 2.0LG H x HD,GR5,Tap
71 HW-00165 Washer, Lock Ex 5-16 Zinc
72 FM-16774 Spacer, Motor Base
73 HB-16426 Bushing, Flanged,1.0ID x 1.12OD x .75LG
74 HX-16425 Ring, Retaining Ext Crescent
75 FT-16352 Shaft, Motor Mount
76 AW-16830 Cable, Opto Sensor, Armored
77 HW-10772 Washer, Flat No. 4
78 HW-10761 Washer, Lock Ex No.6 Zinc
79 HS-00156 Screw, 4-40 x 0.62 Pnhd Phil
80 AF-17792 Clamp, Motor Drive (includes nut)
81 SK-17246 Motor, 3.0 Hp 110v, PMDC 3500RPM GR
81 SK-17245 Motor, 3.0 Hp 220v, PMDC 3500RPM WH
82 DE-16542 Disc, Speed Sensor
83 FM-16463 Flywheel, Drive Pulley Machined
84 HX-11593 Key, Ansi Square 3-16 x 1 3-16
Cybex Pro+ Treadmill Owner’s & Service Manual
Service
Page 7-40
