ITEM PART NO. DESCRIPTION
NO.
86 HW-00180 Washer, Lock Split 1/4
87 HS-15757 Bolt, Tap 1/4-28 x 1.0 H x HD PLTD
88 PC-16379 Cover, Junction Outer, Right, (Choose a Standard or Custom Color)
89 PC-16380 Cover, Junction Inner, Right, (Choose a Standard or Custom Color)
90 PC-16328 Cover, Junction Inner, Left, (Choose a Standard or Custom Color)
91 PC-16327 Cover, Junction Outer, Left, (Choose a Standard or Custom Color)
92 DK-16932 Deck, Plywood 23.3 x 51.5 x 1.0 (Double Sided)
93 BD-16853 Belt, Running, 20.63 x 58 Commercial
94 HW-00431 Washer, 1-4 x .75 x .062 Zinc
95 HS-16628 Screw, .25-20 x 1.5 Hxhd Grade 8
96 AL-16245-1 Roller, Front Assy
97 AL-16235-1 Roller, Rear Assy
98 BD-16829 Drive, Belt, 8 Rib
99 PL-17659 Console, Back, Plastic
100 DE-17712 Decal, Logo, Cybex Intl, 9 x 7”
101 AC-17695-4 Entire Console, Cybex Pro+, English
101 PL-17658 Front Console, Plastic
102 SW-17185-4 Switch Membrane, Cybex Pro+ Top, English
103 SW-17187-4 Switch Membrane, Cybex Pro+ Bottom, English
104 AX-16944 Lanyard, E-stop Assembly
105 PL-17686 Tab, Bookholder
107 AD-16559 PCA, Handset Display with Wireless Heart Rate
108 AD-17105 PCA, Cybex Pro+ Display Board, 4 Layer
109 FS-16841 Mount, E-stop Magnet
110 AD-17690 PCA, CSAFE Port Board, W-TVS
111 EC-17763 PCA Salutron Serial Output
112 AW-17707 Cable, CHR to display with ferrite
113 AF-17684 Handrail, Weldment
114 SK-17827 Kit, Assembly, Contact Heart Rate Grip, Pair
115 HX-17788 Double-sided Tape
116 HX-15499 Grip Handlebar
117 HX-16931 Clamp, Cable, 5-16 dia Standard
118 HS-10716 Screw 4-40 x 0.38 PNHD Phil
119 EH-00472 Wire Tie Ty-23M
120 HX-17696 Clamp, Cable 5-8 Dia.
121 HS-16940 Screw, Sems 10-32 x 3-8 PNHD ext, BL ZN
122 FS-16990 Plate, Switch, Power On-Off
123 SW-10523 Switch, On-Off
124 HS-41187 Screw, 8-16 x 5-16 Plastite
125 HS-15706 Screw, 8-16 x .50 PNHD STL BLK Phil
126 HX-17711 Plug, Hole Plastic 7-16 Black
127 ET-17165 Tab, Faston .250 Series AMP, International Only
128 DE-16784 Decal, Side Stripe
129 DE-17714 Decal, Cybex, Side
130 HX-17822 O-Ring
NS LT-17730-4 Owner’s & Service, Manual Cybex Pro+, English
NS LT-17718 Poster, Assembly
NS LT-17446 Warranty Sheet, Cybex Pro+, Pink
NS HX-00438 Hex Key 3-16"
NS EH-16954 Cap, Motor Brush Access, Round
NS EH-16955 Cover, Motor Brush Access
NS SK-17269 Brush Kit, Pair, High Voltage, 2.5 & 3.0hp Leeson Motor
NS AX-17217 Handrail Extension Kit, Left & Right - Complete kit with instructions
NS AX-17174 Handrail Extension Kit, Left Only - Complete kit with instructions
NS AX-17175 Handrail Extension Kit, Right Only - Complete kit with instructions
NS HS-16921 Bolt, 5/8-11 x 4.75, Black Zinc - Bottom hardware
NS AX-16273 Clamp Assy, Handrail Ext.
NS HX-16852 Grip, Handrail Extension
NS HS-16935 Screw, Set 1-2 13 x 1-2, Knurl pt - Top Hardware
NS FT-16278 Spacer, Handrail Ext - Bottom hardware
NS AW-16572 Jumper, Switch-Filter, White
NS AW-16938 Jumper, Switch-Filter, Black
NS AW-16578 Jumper, Filter-cntl, White
NS AW-16579 Jumper, Filter-cntl, Black
NS AW-16561 Cable, Univ. Tread Display
NS AW-17706 Cable, Contact HR Grip
NS AW-17732 Cable, 4” Ribbon C-SAFE
NS DE-17713 Cybex Pro+ Decal for Side Extrusions
NS CN-10418 Connector, Molex (Placeholder)
NOTE: NS = Not Shown
Cybex Pro+ Treadmill Owner’s & Service Manual
Service
Page 7-41
