Cygnus 4 Operating Manual
To avoid damage from leaking batteries always remove the
batteries if the gauge will be unused for any length of time.
If the batteries run flat they may leak acid into the battery
compartment and damage the electrical contacts. This would
not be covered by the warranty.
Connecting the Probe
The Cygnus probe lead uses a custom made cable that offers
superior flexibility and resistance to oils and ultraviolet light. The
cable will not stiffen after exposure to ultraviolet light.
The connector uses original Lemo connectors for reliability.
Depending on the type of probe supplied the probe end will have
either a BNC or single Lemo 00 connector.
simply pull back on the
connector body. DO NOT
pull the cable.
Fitting the Neck Strap
The gauge is supplied with an adjustable Neck Strap. The ends of
the neck strap clip onto two wire loops fitted to the gauge. These
wire loops are made from coated stainless steel.
