Cygnus 4 Operating Manual
53
13. Information
Technical Specifications
Cygnus M5-C4 Technical Specifications
General Attributes
Size
84 mm x 130 mm x 35 mm (W x H x D)
(3.3 in x 5.1 in x 1.4 in)
Weight
Gauge with batteries 300 g (10.5 oz.)
Power Supply
3 x AA / R6 Batteries.
Probe Socket
1 x Lemo 1S
Operating Temperature Range
-10°C to +50°C (14°F to 122°F)
Storage Temperature Range
-10°C to +60°C (14°F to 140°F)
Battery Operation Time
Approximately 10 hrs. continuous measurement with fully
charged Duracell Alkaline LR6 batteries.
Battery Voltage Range
Min 3.0 V dc, Max 4.5 V dc
Battery Type
AA Size. LR6 Alkaline / HR6 NiMH.
Low Battery Indication
Battery level indication on display with low battery warning
message.
PRF
N/A
Monitor Outputs
N/A
Through Coating
Measurements
Multiple-Echo mode with Single element 0° probe;
• Through coating measurement for coatings up to 3 mm
thick as standard depending on coating velocity with S2C
probe.
• Deep Coat mode provides ability to measure through
thicker coatings depending on coating material with S2C
probe.
Materials
Sound velocity from 1000 m/s to 9000 m/s
[0.0390 in/us to 0.3543 in/us]
Measurement Ranges
Measurement ranges in steel.
Single element 0° probes in Multiple Echo mode;
S2C/D probe
3 to 250 mm
[0.120 in. to 10.00 in.]
S3C probe
2 to 150 mm
[0.080 in. to 6.000 in.]
S5C/A probes
1 to 50 mm
[0.040 in. to 2.000 in.]
Probe Zero
Single element probes in multiple echo mode do not need to
be zeroed.
Measurement Modes
Multiple Echo using Single element probe. Uses three matched
and verified back-wall echoes to determine the material
thickness and ignore surface coatings.
High Temperature
All standard single element and twin element probes:
