Cygnus 4 User Manual

Cygnus 4 Operating Manual
M5-CYG4-M-01_Iss6.doc
54
Cygnus M5-C4 Technical Specifications
Measurement
Allows continuous measurement up to 75°C (160°F).
Resolution
Multiple Echo measurement modes;
Low
(measurement > 120 mm)
0.1 mm
[0.005”]
Medium
(measurement < 120 mm)
0.05 mm
[0.002”]
Accuracy
±0.1 mm (±0.004”) or 0.1% of thickness measurement whichever is
the greatest.
Display
Type of Display
Colour TFT LCD with LED Backlight
Display Size
240 x 128 Pixels QVGA. 2.4“, 47 mm (W) x 37 mm (H)
Display Information
Digital Thickness Value. Settings. Battery Level.
Transmitter
Shape of Pulse
Square
Pulse Energy : Voltage (peak-
to-peak)
70 V p-p
Pulse Energy : Rise Time
3 ns (max)
Pulse Energy : Pulse Duration
S2C : 220 ns
S2D : 220 ns
S3C : 100 ns
S5A / S5C : 67ns
Receiver
Gain Control
Automatic Gain Control depending on probe and measurement
mode.
Frequency Range
1.0 MHz to 10.0 MHz (-6dB)
Other Information
Data Output and Storage
Non.
Data Connector
USB Mini B Connector under battery cover.
Calibration setting storage
Calibration Data stored to Internal Flash Memory
Calibration Mechanisms
Single Point calibration of velocity of sound in Multiple Echo
mode.
Display & Recall Facilities
N/A
Display Response Time
125 ms / 500 ms
Printer Output
N/A
Environmental Rating
IP67 (Water immersion 1 metre depth for 30 minutes)
MIL STD 810G Method 501.6 (High Temp +55°C)
MIL STD 810G Method 502.6 (Low temp -20°C)
MIL STD 810G Method 507.6 (Humidity 95%)
MIL STD 810G Method 512.6 (Immersion 1m, 30min)
Shock & Impact
MIL STD 810G Method 514.7 (Vibration)
MIL STD 810G Method 516.7 (Shock 20g)
