DES-3526 / DES-3526DC Fast Ethernet Layer 2 Switch
93
Figure 6- 60. Access Rule Table window
To remove a previously created rule, select it and click the
button. To add a new Access Rule,
click the Add button:
Figure 6- 61. Access Rule Configuration window (Ethernet)
To set the Access Rule for Ethernet, adjust the following parameters and click Apply.
Parameters Description
Profile ID
This is the identifier number for this profile set.
Mode
Select Permit to specify that the Switch, according to any additional rule, forwards the
packets that match the access profile added (see below).
Select Deny to specify that packets that do not match the access profile are not
forwarded by the Switch and will be filtered.
