DES-3526 / DES-3526DC Fast Ethernet Layer 2 Switch
152
Figure 8- 1. Utilization window
The following field can be set:
Parameter Description
Time Interval
Select the desired setting between 1s and 60s, where "s" stands for seconds. The
default value is one second.
Record Number
Select number of times the Switch will be polled between 20 and 200. The default
value is 200.
Click Clear to refresh the graph. Click Apply to set changes implemented.
CPU Utilization
The CPU Utilization window displays the percentage of the CPU being used, expressed as an integer
percentage and calculated as a simple average by time interval. To view this window, open the
Monitoring folder and click the CPU Utilization link.
