DES-3526 / DES-3526DC Fast Ethernet Layer 2 Switch
74
Figure 6- 43. Bandwidth Settings window
The following parameters can be set or are displayed:
Parameter Description
From/To
A consecutive group of ports may be configured starting with the selected port.
Type
This drop-down menu allows you to select between RX (receive), TX (transmit), and Both.
This setting will determine whether the bandwidth ceiling is applied to receiving,
transmitting, or both receiving and transmitting packets.
no_limit
This drop-down menu allows you to specify that the selected port will have no bandwidth
limit. Enabled disables the limit.
Rate
This field allows you to enter the data rate, in kb/s, that will be the limit for the selected
port.
Click Apply to set the bandwidth control for the selected ports. Results of configured Bandwidth
Settings will be displayed in the Port Bandwidth Table.
