6D-Link DIR-890L User Manual
Section 1 - Product Overview
Hardware Overview
LEDs
1 32 4
5
6
1 SS USB LED A solid white light indicates a USB 3.0 device is connected.
2 USB LED A solid white light indicates a USB 2.0 device is connected.
3 5G LED
A solid white light indicates the 5GHz wireless function is working properly. During the WPS process,
this light will blink quickly.
4 2.4G LED
A solid white light indicates the 2.4GHz wireless function is working properly. During the WPS process,
this light will blink quickly.
5 Internet LED
A solid white light indicates a connection to the Internet port. If the LED is orange, the connection is
good but the router cannot connect to the Internet.
6 Power LED
A solid white light indicates a proper connection to the power supply. The light will be solid orange
during boot-up.

Table of Contents

Other manuals for D-Link DIR-890L

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DIR-890L and is the answer not in the manual?

D-Link DIR-890L Specifications

General IconGeneral
VPN supportPPTP/L2TP/IPsec
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Wi-Fi bandTri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)3200 Mbit/s
WLAN data transfer rate (first band)600 Mbit/s
WLAN data transfer rate (second band)1300 Mbit/s
USB version2.0/3.2 Gen 1 (3.1 Gen 1)
Input current5 A
Rack mountingNo
Frequency band2.4 & 5 GHz
USB ports quantity2
WLAN data transfer rates supported600, 1300 Mbit/s
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
DHCP client-
Antennas quantity6
Security algorithmsWPA, WPA2, WPS
Product typeTabletop router
Product colorRed
CertificationIC\\r CE\\r Wi-Fi Certified\\r FCC
Output voltage12 V
AC input voltage100 - 240 V
Power source typeDC
AC input frequency50 - 60 Hz
Storage temperature (T-T)-20 - 65 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)0 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth387 mm
Width247.3 mm
Height119.5 mm
Weight- g
