D-Link DIR-890L - Manual Setup

10D-Link DIR-890L User Manual
Section 2 - Installation
1 2 3 4
USB 2.0USB 3.0
POWER
WSP
DCN IN
12V
SA
...
-
RESET
INTERNET
1. Turn o and unplug the power to your cable or DSL modem. This is required.
Manual Setup
2. Connect an Ethernet cable from the Internet port of the router to the Ethernet port on your cable or DSL modem.
Modem
Ethernet Port
Modem
Ethernet Cable
DIR-890L
Internet Port (yellow)
