6D-Link DSL-226 User Manual
Section 1 - Product Overview
Side Panel
1
WLAN/WPS Button
Long Press: Press to enable or disable the wireless function. Press and hold this button for about 4
seconds and release it to enable or disable the wireless function.
Short Press: Press to start the WPS process and automatically create an encrypted connection to a
WPS client. Refer to the next page for the LED indicators of the WLAN and WPS functions.
2 USB 2.0 Port Connects to USB ash drives to share content.
3
Reset Button
(on the bottom of
the device)
Press to reset the device to its factory default settings. Press the reset button by inserting the end
of a straightened paper clip into the hole and hold this button for about 5 seconds and release it
to reset the device. During the reset process, all lights will turn o and back on again.
1
3
2
