D-Link DSL-2600U User Guide

Web Configuration
D-Link DSL-2600U User Manual
76
Both the log level and display level have eight choices. The default log level is Debugging
and the default display level is Error.
The mode options are Local, Remote, and Both. The default is Local.
If you select Remote or Both, all events are transmitted to the specified UDP port of the
specified log server.
After operations under Configure System Log, click View System Log to query the
system logs. In this example, the View System Log is the default.
Note: The log and display of the system events are above the set level. If you intend to
record all information, you need to set the levels as Debugging.
Click Refresh to refresh the system event logs or click Close to exit from this interface.

D-Link DSL-2600U Specifications

Power

input voltage	100V-240V
input current	0.6A
input frequency	50 Hz - 60 Hz
output voltage	12V
output current	1A

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite ADSL downstream	up to 1.5 Mbps
G.lite ADSL upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 1 Mbps
ADSL2+ full rate downstream	up to 24 Mbps
ADSL2+ full rate upstream	up to 1 Mbps
IEEE 802.11b wireless transfer rates	11, 5.5, 2, and 1Mbps
IEEE 802.11g wireless transfer rates	6, 9, 12, 18, 24, 36, 48, 54 Mbps

Interfaces

ADSL interface connector	RJ-11
LAN interface port	RJ-45
LAN interface standard	10/100BASE-T Ethernet
