D-Link DSL-2600U User Guide

Web Configuration
D-Link DSL-2600U User Manual
41
Parental Control
Click Security>Parental Control and the following page appears.
Click Add and the following page appears.
In this page, you can add time of day restriction to a special LAN device connected to the
Router. The Browser's MAC Address automatically displays the MAC address of the LAN
device where the browser is running. To restrict other LAN device, click Other MAC
Address and enter the MAC address of the another LAN device. To obtain the MAC
address of a Windows based PC, enter ipconfig /all in the DoS window.
URL Filter
Choose Advanced Setup > Parental Control > Url Filter, and the Url Filter page
appears. In this page, there are two URL list types – Exclude and Include. If select
Exclude, LAN devices could not access Url addresses in the list. And so if select Include,
LAN devices just could access Url addresses in the list. Otherwides, one of list types
should be selected.

D-Link DSL-2600U Specifications

Power

input voltage	100V-240V
input current	0.6A
input frequency	50 Hz - 60 Hz
output voltage	12V
output current	1A

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite ADSL downstream	up to 1.5 Mbps
G.lite ADSL upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 1 Mbps
ADSL2+ full rate downstream	up to 24 Mbps
ADSL2+ full rate upstream	up to 1 Mbps
IEEE 802.11b wireless transfer rates	11, 5.5, 2, and 1Mbps
IEEE 802.11g wireless transfer rates	6, 9, 12, 18, 24, 36, 48, 54 Mbps

Interfaces

ADSL interface connector	RJ-11
LAN interface port	RJ-45
LAN interface standard	10/100BASE-T Ethernet
