D-Link DSL-G225 User Manual

11D-Link DSL-G225 Wireless N300 ADSL2+/VDSL2 Modem Router User Manual
Section 2 - Installation
6
7
If connecting to the DSL-G225 wirelessly, access the wireless utility on your computer or mobile device. Scan
for available Wi-Fi networks (SSID). Select and join a Wi-Fi network and use the password which corresponds
to the information printed on the bottom of the device.
Press the power button and verify that the power LED is lit. Allow 1 minute for the router to boot up.

D-Link DSL-G225 Specifications

Power

input voltage	100~240 V
input frequency	50~60 Hz
output voltage	DC 12 V

Operating Environment

operating temperature	0 to 40 °C
non-operating temperature	-20 to 65 °C
operating humidity	0% - 90% non-condensing

Weight and Dimensions

dimensions	131.5 x 74.3 x 185.4 mm
weight	285 grams
