D-Link DSL-G225 User Manual

57D-Link DSL-G225 Wireless N300 ADSL2+/VDSL2 Modem Router User Manual
Section 4 - Conguration
WAN
Connection:
Select the interface to use with the rule.
Select a
Service:
Select an service for a preset application or enter a name in Custom
Server.
Schedule: Select a schedule or choose Always.
Server
IP Address:
Enter an IP address to appoint the corresponding client to receive
forwarded packets.
External Port
Start/End:
Enter the external port(s).
Protocol: Select TCP or UDP.
Internal Port
Start/End:
Enter the internal port(s).
LAN
Loopback:
Check the box to enable the LAN loopback feature.
PORT FORWARDING
Click Apply when you are done.

D-Link DSL-G225 Specifications

Power

input voltage	100~240 V
input frequency	50~60 Hz
output voltage	DC 12 V

Operating Environment

operating temperature	0 to 40 °C
non-operating temperature	-20 to 65 °C
operating humidity	0% - 90% non-condensing

Weight and Dimensions

dimensions	131.5 x 74.3 x 185.4 mm
weight	285 grams
