D-Link DWM-156 User Manual

21D-Link DWM-156 User Manual
Section 7 - Text Messaging (SMS)
New/Reply/Forward Text Message
1. Click the SMS button.
2. Click New, Reply, or Forward.
3. Enter the recipient’s phone number or click Contacts to see the
contacts stored to the SIM card. In the contacts window, click
the box next to the recipients name and click Add to return to
the New SMS window.
4. Enter a message to send.
5. Click Send to send the message.
Deleting a Message
Saving a Sender to Contacts
1. Click the SMS button.
2. Select the messages you want to delete. If you would like to delete all messages, click Select All.
3. Click Delete to delete the selected messages.
4. Click Yes to conrm.
1. Click the SMS button.
2. Select a message.
3. Right click on the selected message and click Save to Contacts.
4. In the Add Contact window enter the contact name.
5. Click OK to save the contact.
6. Once the contact has been saved, a conrmation window will be
displayed. Click OK to close it.

D-Link DWM-156 Specifications

GSM and UMTS Specifications

GSM Band	850, 900, 1800, 1900 MHz
UMTS/HSDPA Band	850/1900/2100 MHz
Power Class 4	900 / 1850 MHz

Data Rates

Download Speed	7.2 Mbps (HSDPA)
Upload Speed	5.76 Mbps (HSUPA)
Power Class 3	+24 dBm

Dimensions and Operating Environment

Dimensions	86.75 x 28 x 11.4 mm
Operating Temperature	-10˚ to 55˚C (14˚ to 131˚F)
Supported MicroSD Card Capacity	up to 8GB
