D-Link DWM-156 User Manual

26D-Link DWM-156 User Manual
Section 9 - SIM Management
Enabling or Disabling a PIN Code
Enable PIN Code
To prevent unauthorized use of the SIM card a PIN code can be enabled.
1. Select Tools > Enable/Disable PIN code > Enabled.
2. Enter the correct PIN code to enable.
3. Click OK to enable PIN code protection.
If a PIN number has been enabled, you will always be asked to enter it before
accessing the D-Link Mobile Connection Manager software.
Disable
If a PIN code is no longer required, you may disable it via the following
steps.
1. Click Tools > Enable/Disable PIN code > Disabled.
2. Enter the correct PIN code.
3. Click OK to disable the PIN.
Note: The PIN is provided by your network service provider.
Warning: The PIN code must be entered correctly within three tries. Failure
to do so will cause the SIM card to become locked.


D-Link DWM-156 Specifications

GSM and UMTS Specifications

GSM Band	850, 900, 1800, 1900 MHz
UMTS/HSDPA Band	850/1900/2100 MHz
Power Class 4	900 / 1850 MHz

Data Rates

Download Speed	7.2 Mbps (HSDPA)
Upload Speed	5.76 Mbps (HSUPA)
Power Class 3	+24 dBm

Dimensions and Operating Environment

Dimensions	86.75 x 28 x 11.4 mm
Operating Temperature	-10˚ to 55˚C (14˚ to 131˚F)
Supported MicroSD Card Capacity	up to 8GB
