DESCRIPTION OF OPERATION GENERATORS SECTION
Sine
Kick tone body generator based on amplitude and frequency modulaon of the sine waveform.
The rst row provides the parameters to control the amplitude envelope:
• Aack
• Hold - From 1 [ms] up to 1[s]
• Decay
The next row provides the parameters to control the oscillator frequency modulaon:
• Start Freq – Inial frequency from 5 [Hz] up to 8 [kHz]
• End Freq – Final frequency from 5 [Hz] up to 115 [kHz]
• Sweep Time – Modulaon rate from 1 [ms] up to 1[s]
The last row provides the parameters to control the amplitude and frequency modulaon characterisc:
• Aack Curve – Amplitude aack curve
• Decay Curve – Amplitude decay curve
• Sweep Curve – Frequency modulaon characteriscs / curve
The last parameter, Level, controls the generator’s output volume.
