DESCRIPTION OF OPERATION EFFECTS SECTION
Mixdown Aer
The Send parameters of the Generators secon decide on the signal proporons sent to the eect cascade and directly to Master / Limiter.
Audio Mixdown in the Eects secon
Mixdown Aer can modify the posion where the generator signal joins (mixes with) the processing path in the eects secon.
Signal eects secon ow diagram with Mixdown Aer
By default, Mixdown Aer is set to FX4. It means that the generator signal ows over two paths; the primary generator signal bypasses
the eect block and is sent to the Master / Limiter (blue path), the send generator signal is sent to the eect block and processed by the
eects before it enters the Limiter (red path). Mixdown Aer controls the posion where the primary signal joins (sums up with) the send
signal.
