dacell DN-100 User Manual

# Function mode list #
Name Function Setting Standard value
F-01 Decimal point 0, 1, 2, 3 1
F-02 Division 1, 2, 5, 10, 20, 50 1
F-03 Display filter 0, 4, 8, 16, 32 8
F-04 Hold mode
Display SH, Digital SH, Display PH(+),
Absolute PH(±), Analog PH(+),
Average (DN-100, DN-150)
Display PH(+)
F-05 Comparison mode
Decision, High limit, Low limit,
Low&High limit
Decision
F-06 Hysteresis 0 ~ 99 0
F-07 DAC mode Display DAC, High speed DAC Display DAC
F-08 DAC capacity -19999 ~ +99999 10000
F-09 ID Number 0 ~ 32 0
F-10 Baud rate & PRINT 2400, 4800, 9600, 19200, 38400, 57600, print 9600
F-11 Auto zero tracking 0 ~ 99 0
F-12 Auto zero tracking time 0.0 ~ 5.0 sec 0.0
F-13 Force unit Kg(kg/㎠), N, ℓb, bar, MPa Kg
F-14 Key disabling Zero key, Lo key, Hi key, Hold key 0000
F-15 BCD BUSY 0.010, 0.020, 0.050, 0.100, 0.200, 0.500, 1.000 0.100
F-01. Decimal point (Decimal point set-up)
16
(Standard setup value: 1)
Display data Setting
0 00000 : No decimal point
1 0000.0 : One decimal place
2 000.00 : Two decimal places
3 00.000 : Three decimal places
