F-02. Division (Minimum display unit setup)
(Standard setup value: 1)
Display data Setting
1 Displayed In 1 (0, 1, 2, 3, 4 …….)
2 Displayed in 2 (0, 2, 4, 6, 8 …….)
5 Displayed in 5 (0, 5, 10, 15 …….)
10 Displayed in 10 (0, 10, 20, 30 …….)
20 Displayed in 20 (0, 20, 40, 60 …….)
50 Displayed in 50 (0, 50, 100, 150 …….)
F-03. Display filter (Display speed setup)
(Standard setup value: 8)
Display data Setting
0 No filter
4 Average time 1/8 sec
8 Average time 1/4 sec
16 Average time 1/2 sec
32 Average time 1 sec
F-04. Hold mode
(Standard setup value: 2)
Display data
Setting
0
Display sample Hold
: To hold the display value at the time of Hold signal input.
1
Digital sample Hold
: To hold the A/D convertion value at the time of Hold signal
input.
2
Diplay Peak Hold :
To hold the maximum value of display values during Hold signal input.
3
Absolute Peak Hold
:
To hold the maximum absolute value of display values during
Hold
signal input.
4
Analog Peak Hold
:
To hold the maximum value of sensor input during Hold signal input.
5
(DN-100,150)
Average Hold :
To hold the average value of sensor input during Hold signal input.
F-05. Comparision mode (Comparision output mode setup)
17
(Standard setup value: 0)
Display data Setting
0 Decision mode : Relay RY1(Lo), RY2(Hi), RY3(Ok) output
1 High limit mode : Relay RY1, RY2, RY3, RY4 output
2 Low limit mode : Relay RY1, RY2, RY3, RY4 output
3
Low & High limit mode
: Relay RY1, RY2, RY3, RY4 output
