dacell DN-100 User Manual

F-06. Hysteresis
(Standard setup value: 00)
Display data Setting
00 00 : Hysteresis – not used
~
99 01 ~99 : Hysteresis – used (Decision mode is not applied)
F-07. DAC mode (Analog Output mode setup)
(Standard setup value: 0)
Display data Setting
0 Display DAC mode : Convert the current display value and do
the analog output.
1 High speed DAC mode : Convert A/D input value and do the analog
output.
F-08. DAC capacity (Analog Outupt value setup)
(Standard setup value: 10000)
Display data Setting
-19999
~
+99999
To setup the rated capacity of analog output
<Example of Setup value and output>
Voltage Outupt (±10V) Current Output (4 ~20mA)
Setup Value
Display Value Output Display Value Output
-10000 -10V -10000 -
0 0V 0 4mA
+10000
+10000 +10V +10000 20mA
-10000 +10V -10000 20mA
0 0V 0 4mA
-10000
+10000 -10V +10000 -
1
F-09. ID Number (Communication Device Number setup)
(Standard setup value: 00)
Display data Setting
00 00 : Device number is not set-up
~
(Stream mode : always transmit data )
32 01 ~32 : Device number is set-up
(Command mode : Transmit data by command)
18
