F-10. Baud rate & Print (Communication Speed & print output Setup)
(Standard setup value: 9.60)
Display data Setting Stream mode Command mode
2.40 2400 bps O O
4.80 4800 bps O O
9.60 9600 bps O O
19.20 19200 bps O X
38.40 38400 bps O X
57.60 57600 bps O X
PRINT PRINT DATA OUT (PT-100) - -
F-11. Auto zero tracking (Auto zero operation range setup)
(Standard setup value: 00)
Display data Setting
00 00 : Auto Zero is not used.
~
99 01 ~99 : Set up the operation range of auto zero
F-12. Auto zero tracking time (Auto Zero tracking time setup)
(Standard setup value: 0.0)
Display data Setting
0. 0 0.0 : Auto Zero is not used.
~
5.0 0.1 ~5.0 : Set up the auto zero operation time (0.1 ~ 5.0 sec)
F-13. Force unit (Conversion Unit setup)
(Standard setup value: 0)
Display data Setting
0 kg.f kg/㎠
1 N kgf × 9.8 - -
2 ℓb kgf × 2.2 - -
3 - - Bar kg/㎠ × 0.98
4 - - MPa kg/㎠ × 0.098
Note) During calibration, set up the unit you want after calibrating it into Kg.
19
