10-6
FRONT WHEEL/FRONT FORK/STEERING
Bearing Inspection
Manually turn the bearing inner race, and replace if it
makes noise or is worn. Check if the bearing outer race
is accurately fitted into the wheel hub, and replace
worn ones.
·Replace bearings in pairs (left and right set).
FRONT WHEEL DISASSEMBLY
Remove
- Speedometer gear box.
- Dust seal.
- Speedometer gear retainer.
Remove the front brake collar A.
Remove te dust seal and brake disc.
Check the disc for defects.
SPEEDOMETER GEAR BOX
FRONT BRAKE
COLLAR A
FRONT BRAKE DISK
