● Remove the oil tank cap and fill the oil tank with oil to
the level of the projected portion
RECOMMENDED OIL : ULTRA 2 SUPER OIL
● Reinstall the oil tank cap and check to see if the pilot
lamp turns off when the main swich is turned on.
TRANSMISSION OIL INSPECTION
● Check the body and the connection of each engine
component for any leak.
● Remove the oil check bolt and check to see if the oil
overflows from the oil check hole.
● If only the small amount of oil overflows, fill the
recommended transmission oil through the oil filler
hole gradually.
•Oil level inspection must be performed in the flat
ground with the vehicle being straight by raising the
main stand.
RECOMMENDED OIL : SAE 80W / 90
● Tighten the oil level check bolt.
TIGHTENING TORQUE : 1.3kgf
·
m
● Start the engine and check for leak.
4-7
LUBRICATION SYSTEM
