10-9
FRONT WHEEL/FRONT FORK/STEERING
● Apply grease to the dust seal rim.
● Install the dust seal, and align the tangs of the
speedometer gear retainer with the gear groove to
assemble the speedometer gear box.
TUBELESS TIRE
REMOVAL
● Remove the wheel.
·Single brake disk type : To prevent damage to the
disk, place the wheel on the level surface with the
disk facing up.
·Double brake disk type : Remove one disk first, then
place the wheel on the level surface with the other
disk facing up.
● Remove the valve cap and bleed air by pressing the
valve core.
● Remove the valve core after bleeding air completely.
● Remove the valve stem nut and push the valve stem
lightly.
● If a bead stopper is installed, loosen the lock nut and
push the bead stopper down.
● Collapse in the bead with a tire bead breaker.
● If no tire bead breaker is available, step on the side wall
to collapse the bead.
·Do not step on the rim.
● Collapse the bead into the rim center and slide the tire
out of position.
·Tire can be easily removed once the beads are
collapsed completely.
● Apply a mild detergent solution to the rim and tire
mating surfaces.
