3. EXTERNAL PARTS
SERVICE INFORMATION
● This section describes external parts removal/installation.
● Do not apply unreasonable force when disassembling covers, to prevent possible damage.
● A muffler is hot. Do not service it immediately after the engine is stopped.
3
SERVICE INFORMATION 3-1
MAINTENANCE PRECEDURE 3-2
LUGGAGE BOX
3-3
PLUG MAINTENANCE
COVER/CENTER COVER
3-3
REAR CARRIER
3-3
BODY COVER
3-3
TAILLIGHT BASE
3-4
FLOOR SIDE COVER
3-4
FLOOR PANEL
3-4
ENGINE HANGER SIDE COVER 3-5
FRONT COVER
3-5
FRONT FENDER
3-5
INNER COVER
3-5
FRONT UNDER COVER
3-6
MUFFLER
3-6
REAR FENDER
3-7
REAR WHEEL MUD GUARD
3-8
UNDER COVER
3-8
