SERVICE INFORMATION
GENERAL SAFETY
•Gasoline is extremely flammable. Avoid fire in the work place, also paying particular attention to sparks.
Furthermore, the evaporated (gasified) gasoline is highly explosive. Work in a well-ventilated areas.
•Exhaust gas contains poisonous substance. Do not keep engine running for a long period of time in a closed, or poorly
ventilated area.
•Do not excessively bend or twist cable. Distorted or damaged cable may lead to mechanical malfunctions.
•Pay particular attention to the position of O-ring. Replace with new ones when disassembled.
•If it is desired to store a vehicle for a period longer than 1 month, drain gasoline out of the carburetor float chamber.
Gasoline left in the float chamber will be deteriorated causing the slow jet to be clogged with deposits, and idling may
become unstable.
SPECIFICATIONS
FUEL TANK CAPACITY : 5.8ℓ
RESERVE FUEL CAPACITY: 1.7ℓ
CARBURETOR
TOOL
FLOAT LEVEL GAUGE
5-1
5. FUEL SYSTEM
5
SERVICE INFORMATION 5-1
TROUBLESHOOTING
5-2
FUEL TANK
5-3
AIR CLEANER REMOVAL
5-4
AIR CLEANER ELEMENT
DISASSEMBLY 5-4
ITEM
TYPE/THROTTLE BORE
VENTURI DIAMETER
MAIN JET No.
SLOW JET No.
STANDARD
PB11P
16mm OR EQUIVALENT
#65
#38
ITEM
PILOT SCREW OPENING
FLOAT LEVEL
IDLING SPEED
THROTTLE GRIP FREE PLAY
STANDARD
1, 1/4 RETURNS
8.0mm
1,800±100rpm
2-6mm
CARBURETOR REMOVAL/
INSTALLATION
5-4
CARBURETOR INSPECTION
5-6
THROTTLE VALVE
5-7
FUEL AUTO COCK
5-8
INLET PIPE REED VALVE 5-9
