DAELIM a.four User Manual

1-11
SERVICE INFORMATION
ITEM STANDARD
FUEL SYSTEM
FUEL TANK CAPACITY FULL CAPACITY
AIR CLEANER TYPE
CARBURETOR SETTING MARK
VENTURI DIAMETER
AIR SCREW OPENING
FLOAT LEVEL
IDLING RPMS
NO. OF JET NEEDLES
MAIN JET
SLOW JET
THROTTLE GRIP CLEARANCE
CYLINDER HEAD, CYLINDER, PISTON
PORT OPEN/CLOSE PERIODS INHALATION OPEN
CLOSE
EXHAUST OPEN
CLOSE
SCAVENGING OPEN
CLOSE
CYLINDER HEAD COMPRESSION PRESSURE
CYLINDER ID MARK LOCATION
INSIDE DIAMETER ID MARK(A)
NO ID MARK
CYLINDRICAL DEGREE
OUT OF ROUNDNESS
PISTON
OUTSIDE DIAMETER MEASUREMENT LOCATION
OUTSIDE
DIAMETER
OUTSIDE DIAMETER ID MARK(A)
ID MARK(B)
NO ID MARK
CYLINDER AND PISTON CLEARANCE
PISTON PIN HOLE INSIDE DIAMETER
PISTON PIN OUTSIDE DIAMETER
PISTON AND PISTON PIN CLEARANCE
PISTON RING GAP TOP
SECOND
RING MARK
CONNECTING ROD SMALL END PORTION DIAMETER
6ℓ
Urethane Foam
PB11P
ր16mm
1 1/4 Rotation
8.0mm
1,800±100rpm
4
#65
#38
2-6mm
Auto Control
Auto Control
81.5。BBDC
81.5。ABDC
56.5。BBDC
56.5。ABDC
10kgf/㎠-600rpm
Side of Cylinder
39.000-39.005mm
39.005-39.010mm
-
-
38.955-38.960mm
38.965-38.970mm
38.960-38.965mm
0.035-0.050mm
12.002-12.008mm
11.994-12.000mm
0.002-0.014mm
0.10-0.25mm
0.10-0.25mm
Turning up
17.005-17.017mm
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
39.05mm
39.05mm
0.10mm
0.10mm
38.90mm
38.90mm
38.90mm
0.10mm
12.03mm
11.98mm
0.03mm
0.40mm
0.40mm
-
17.03mm
USE LIMITS
3mm
