DAELIM a.four

1-16
SERVICE INFORMATION
SPECIALIZED TOOLS
TOOL NAME
FLOAT LEVEL GAUGE
BEARING DIRVER
BEARING REMOVER
REMOVER HANDLE
REMOVER WEIGHT
DRIVER HANDLE A
OUTER DRIVER 24×26mm
CLUTCH SPRING COMPRESSOR
SOCKET WRENCH 39mm
CLUTCH CENTER HOLDER
UNIVERSAL HOLDER
CRANK ASSEMBLY
DRIVER HANDLE A
OUTER DRIVER 37×40mm
DRIVER PILOT, 17mm
UNIVERSAL BEARING PULLER
CRANK CASE PULLER
CRANK ASSEMBLY
OUTER DRIVER 52×55mm
DRIVER PILOT 20mm
DRIVER HANDLE A
CRANK ASSEMBLY
LOCK NUT WRENCH A
LOCK NUT WRENCH B
BALL RACE REMOVER
OUTER DRIVER, 42×47mm
DRIVER HANDLE A
SHOCK ABSORBER COMPRESSER
COMPRESSER SCREW ASS’Y
SPRING COMPRESSER ATTACHMENT
SPRING COMPRESSER ATTACHMENT
UNIVERSAL HOLDER
A.G.G ROTOR PULLER
TOOL NO.
07401-001000
07945-GC80000
07936-3710300
07936-3710100
07741-0010201
07749-0010000
07746-0010700
07960-KM10000
0723-03900
07724-0050001
07725-0030000
0740-00001
0749-0010000
07746-0010200
07746-0040400
0755-00001
0751-00003
0740-00001
07746-0010400
07746-0040500
07749-0010000
0740-00001
07916-1870101
07916-KM10000
07946-GA70000
07746-0010300
07749-0010000
07GM-0010000
079GME-0010100
07967-GA70102
07JME-GW20100
07725-0030000
0750-00006
USAGE
Carburetor Oil Level Measurement
Change of Driven Face Outer Bearing
Disassembly of Driven Face Needle Bearing
Assembly of Driven Face Needle Bearing
Disassembly/Assembly of Clutch/Driven Face
Disassembly/Assembly of Driven Pulley/Driven Face
Disassembly/Assembly of Clutch /Driven Pulley
Assembly of Drive Shaft
Assembly of Drive Shaft Bearing
Disassembly of Crank Shaft Bearing
Disassembly of R/L Crank Case, Crank Shaft
Disassembly of R.Crank Case, Crank Shaft
Assembly of Crank Shaft Bearing
Assembly of R/L Crank Shaft Oil Seal
Disassembly of Top Cone Race
Assembly of Ball Race
Disassembly/Assembly of Rear Cushion
Disassembly/Assembly of Fly Wheel
Disassembly of Fly Wheel
CHAPTER
5
7
9
10
11
13
