18-5
TROUBLESHOOTING
CAUSE OF TROUBLE
(1) Brake shoe worn.
(2) Brake cam worn.
(3) Shoe and cam contact surface worn.
(4) Brake drum worn.
(1) Brake shoe worn.
(2) Foreign matter in the brake lining.
(3) Brake drum and shoe contact surface curved.
(1) Brake wire defective or expanded.
(2) Only part of the brake shoe makes contact with the
brake drum.
(3) Clay or moisture inside the brake drum.
(4) Brake lining contaminated by grease or oil.
1. If the arrow were mark and the brake
panel mark match with each other.
2. Brake noise.
3. Poor braking.
POOR BRAKE PERFORMANCE
Check brake adjustment.
CAUSE OF TROUBLE
(1) Cushion spring weak.
(2) Overloaded.
(3) Damper oil leaks.
(1) Fork pipe or cushion rod bent.
(1) Sliders stuck.
(2) Cushion stopper rubber damaged.
1. Suspension excessively soft.
2. Suspension excessively hard.
3. Noise from the suspension.
POOR FRONT/REAR SUSPENSION PERFORMANCE
Check tire pressure.
