200416 5-19
Removal and installation
CE ENGINE FUEL SYSTEM
ΧΦ65/75/85 series
4
2
Fleetguard fuel prefilter/water separator
Removing the fuel prefilter/water separator
filter element
1. Place a tray beneath the filter to capture any
escaping fuel.
2. Remove the plug (3) from the water
sensor (2).
3. Remove the filter element (1) of the fuel
prefilter/water separator by turning it anti-
clockwise.
4. Remove the water sensor (2) from the filter
element (1).
Installing the fuel prefilter/water separator
filter element
1. Check by hand whether the coupling for the
filter attachment is securely attached.
2. Lightly lubricate the sealing ring with engine
oil.
3. Fit the fuel prefilter/water separator filter
element (1) until the sealing ring abuts.
Tighten the filter element a further ∂ to •
turn by hand.
4. Turn the water sensor (2) onto the filter
element until it abuts. Turn the water sensor
a further approx. - turn.
Note:
Over-tightening the water sensor (2) may
damage the sensor and/or cause leakage.
5. Fit the plug (3) of the water sensor (2).
6. Vent the fuel system. See "Inspection and
adjustment".
7. Start the engine and check for leaks. If
necessary, retighten the filter element (1) of
the fuel prefilter/water separator by hand.
G0 00 220
1
2
3
