200324 2-1
General
PE ENGINE INLET/EXHAUST SYSTEM
CF65/75/85 series
4
6
2. GENERAL
2.1 LOCATION OF COMPONENTS
1. Turbocharger
2. Exhaust manifold
3. Air intake pipe
4. Exhaust elbow with integrated butterfly valve
5. Exhaust brake valve
M201160
2
3
4
5
1
