200324 4-15
Removal and installation
PE ENGINE FUEL SYSTEM
CF65/75/85 series
4
5
4.9 REMOVAL AND INSTALLATION, FUEL LEVEL ELEMENT
}
When the fuel level element is
removed, a quantity of fuel will
escape. Collect this fuel, bearing in
mind the risk of fire.
Removal, fuel level element
1. Disconnect the earth lead from the battery
terminal.
Note:
To prevent dirt from entering, first clean the
fuel tank.
2. Remove the connector from the fuel level
element.
3. Remove the fuel pipes from the fuel level
element.
4. Turn the fuel level element a quarter turn
anti-clockwise.
5. Carefully remove the fuel level element from
the fuel tank.
6. Replace the O-ring.
Installation, fuel level element
1. Check that the fuel pipes are fitted correctly
in the tank filter.
2. Fit the fuel level element carefully in the fuel
tank.
3. Insert the fuel level element into the hole of
the tank and turn it clockwise a quarter turn.
i 400109
