200324 2-1
General
PE ENGINE FUEL SYSTEM
CF65/75/85 series
4
5
2. GENERAL
2.1 LOCATION OF COMPONENTS
1. Pump units
2. Pump housing
3. Fuel fine filter
4. Fuel lift pump
5. UPEC electronic unit
6. Primer pump
7. Pressure relief valve
i4 00 684
6
5
1
4
7
2
3
