200324 2-1

General

XE ENGINE FUEL SYSTEM

CF65/75/85 series

2. GENERAL

2.1 LOCATION OF COMPONENTS

1. Pump units

2. Pump housing

3. Fuel fine filter

4. Fuel lift pump

5. UPEC electronic unit

6. Primer pump

7. Pressure relief valve

i4 00 683

7 2 64
