200324 2-1

General

ENGINE BRAKE, PE ENGINE

CF65/75/85 series

2. GENERAL

2.1 LOCATION OF EXHAUST BRAKE COMPONENTS

1. Operating cylinder, exhaust brake

2. Exhaust brake valve

3. Supply pressure

4. Butterfly valve

I400533
