CE ENGINE FUEL SYSTEM
5-2
©
200416
Removal and installation
2
ΧΦ65/75/85 series
4
Note:
Note the sequence in which the injector pipes are
removed. They should be re-fitted in precisely the
reverse order.
3. Unscrew the unions on both sides of the pipe
and remove the pipes.
4. Immediately plug the openings.
Installing the injector pipe
1. Clean the injector pipe and blow-clean it with
dry compressed air.
2. Fit the injector pipes in reverse order and
hand-tighten the unions. When all the pipes
and unions are correctly fitted, the unions
must be tightened to the specified torque.
See "Technical data".
3. Fit the connectors of the injectors in the valve
sleeve.
4. Start the engine to bleed the high-pressure
section of the fuel system and inspect all fuel
pipes for leaks.
1
i400482
