PE ENGINE FUEL SYSTEM
4-12
©
200324
Removal and installation
5
CF65/75/85 series
4
10. Fit a dry new timing case seal (6) using the
special tool (DAF no. 1329318).
11. Check whether cylinder 1 is at top dead
centre (TDC on the flywheel, cylinder 6 in
overlap position).
12. Fit the pump housing camshaft gear (4) in
such a position that the idler gear (3) can be
installed in accordance with the marks.
13. Fit the attachment bolts of the pump housing
camshaft gear (4) and idler gear (3) and
tighten to the specified torque. See
"Technical data".
14. Fit the timing cover.
15. Bleed the fuel system. See "Inspection and
adjustment".
46
7
M200841
M201281
2
1
3
4
