TECHNICAL DATA
6-2
©
200416
XE engine fuel system
0
ΧΦ65/75/85 series
4
6.2 TIGHTENING TORQUES
The tightening torques specified in this section
are different from the standard tightening torques
cited in the overview of the standard tightening
torques. The other threaded connections not
specified must therefore be tightened to the
torque cited in the overview of standard
tightening torques.
When attachment bolts and nuts are replaced, it
is important that - unless stated otherwise - these
bolts and nuts are of exactly the same length and
property class as those removed.
Injector pipes
Fuel filter housing
Injectors
(1) Use bolts once only.
Pump housing
(1) Use Loctite 243
Pump units
Fuel lift pump
(1) Use Loctite 243
Injector pipe union nuts 30 Nm
Fuel leak-off pipe union 20 Nm
Fuel filter cap 25 Nm
Clamping piece attachment bolt 30 Nm + 60 angular displacement
(1)
Leak-off pipe banjo bolt 20 Nm
Pressure relief valve 20 Nm
Attachment bolts to connect pump housing to
engine block 60 Nm
Pump housing rear cover attachment bolts 30 Nm
Attachment bolts for pump camshaft locking plate 30 Nm
Attachment bolts for pump housing sealing plates 30 Nm
Attachment bolts for pulse disk on camshaft 30 Nm
(1)
Attachment bolt, camshaft sensor 8 Nm
Non-return valve 45 Nm
Fuel temperature sensor 20 Nm
Bolts for attaching pump units to pump housing 46 Nm
Pump unit electrical connection 1 Nm
Attachment bolts to connect fuel lift pump to
pump housing 30 Nm
(1)
