PE ENGINE INLET/EXHAUST SYSTEM
4-6
©
200324
Removal and installation
6
CF65/75/85 series
4
4.3 REMOVAL AND INSTALLATION, AIR FILTER ELEMENT
Removing the air filter element
1. Loosen the brackets (1) of the air filter cover
(2).
2. Remove the air filter cover (2).
3. Remove the air filter element (3).
4. Clean the inside of the air filter housing and
the air filter cover.
5. When replacing the air filter element, reset
the air filter indicator, if fitted, by pressing the
button on the top of the indicator.
Installing the air filter element
1. Fit the air filter element (3) to the air filter
housing.
2. Fit the air filter cover. Note the position of the
arrow (4) on the air filter cover (2)
3. Fit the clamp brackets (1) around the air
filter.
4. Check that the flexible sealing bellows (5) on
the air intake is not damaged. Replace if
necessary.
i400443
1
5
2
4
3
V300386
i400443
1
5
2
4
3
